$106.00
Add to Cart
New single USB turn CAN debugger with isolation CAN analyzer
More than 10 available
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
Product introduction:
USBCAN debugger with 1 road CAN interface, PC CAN through the USB bus connected to a standard CAN network, constructing the fieldbus test lab, industry control, intelligent building, automobile electronic field house in data processing, data acquisition, data communications network CAN core control unit.
USBCAN debuggers CAN be as a standard, CAN node is a CAN bus product development, CAN bus equipment test, data analysis powerful tools; At the same time, USBCAN debugging instruments have small volume, convenient installation and other characteristics, is the best choice of the portable users of the system.
USBCAN debuggers CAN use our offer tools, USBCAN directly the CAN bus configuration, send and receive. The user CAN also provide reference the DLL dynamic-link libraries, in a routine writing their own applications, convenient developed CAN system application.
USBCAN debugger equipment, CAN bus circuit of the independent DCDC power supply module, photoelectric isolation, so that the interface adapter has a strong anti-jamming ability, greatly improving the system used in the bad environment in reliability.
Hardware parameters:
USB and took the CAN bus protocol conversion;
-vice USB2.0, compatible USB interface support USB1.1;
Support and CAN2.0 CAN2.0 had A B agreement, support and expand the standard frame frame;
-vice two-way transmission, CAN send support, CAN receive;
To support data frame, remote miscalculates frame format;
CAN controller baud rate had in 10 Kbps-1 Mbps CAN choose between, CAN the software configuration;
CAN transceiver used miscalculates is light coupling isolation, has high speed of 1000 V voltage isolation;
With three had CAN controller send buffer, eight hardware FIFO buffer receiving, the highest receive capacity of up to 1200 cycles per second;
USB bus power supply, transiting directly can also external 5 V power supply;
Had isolated module insulation voltage: 1000 Vrms;
-vice working temperature: 0 ~ 70 ℃;
Shell size: 70 * had * 18 45 mm, very small.
Typical application
Through PC or laptop took the USB interface implementation of CAN bus network send and receive;
CAN network had fast data collection, data analysis;
-vice USB interface turn CAN network interface;
Had the industrial field CAN network data monitoring.
Product list
USBCAN miscalculates debugger one.
USB cable had a root, PC can and USBCAN debugger straight even.
Had USBCAN debugger tool software, and Visual c + + CAN test software source code, such as documents, LIB DLL development, user manuals, CAN bus related information
TE31
