CWDM-SFP howfflink SFP Optical Transceivers
More than 10 available
Details
Shipping: US-Mainland: $10.00 (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
Place of Origin:Guangdong China (Mainland)
Model Number:XSFP-W1490-1G-20km
Brand Name:Howfflink
mode type:single mode/ multi-mode
Laser:DFB/FP
Optical receiver:PIN/APD
Connector:SC/LC
Temperature:Industrial temperature/sta...
Distance:10km/20km/40km/80km/120km
Features
1.25Gbps operation
DFB Laser CWDM Transmitter (1450/1470/1490 nm)
Optical wavelengthrange: λc ± 7.5nm
Optical Transmit DMI function
10km reach on 9/125μm SMF
Wide dynamic PIN-PD receiver
Rx Port Return Loss is no less than 30dB
Standard serial ID information compatible with SFP MSA
SFP MSA package with duplex LC connector
LVTTL logic level RX LOS
Very low EMI and excellent ESD protection
+3.3V single power supply
Operating case temperature: -20 to +85°C
Applications
Switch to Switch interface
Switched backplane applications
Router/Server interfac
CWDM
ATM
SONT/SDH/PDH
FDDI
Fiber Channel
Other optical transmission systems
Standard
Compatible with SFP MSA
Compatible with IEEE 802.3z
Compatible with ANSI specifications for Fibre Channel
Compatible with FCC 47 CFR Part 15, Class B
Compatible with FDA 21 CFR 1040.10 and 1040.11, Class I
Compatible with Telcordia GR-468-CORE
RoHS compliance
Description
The SFP transceiver is high performance, cost effective module supporting data-rate of 1.25Gbps 10km transmission distance with SMF.
The transceiver consists of two sections: The transmitter section incorporates a DFB laser. And the receiver section consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA). All modules satisfy class I laser safety requirements.
The optical output can be disabled by a TTL logic high-level input of Tx Disable. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver.
The standard serial ID information compatible with SFP MSA describes the transceiver’s capabilities, standard interfaces, manufacturer and other information. The host equipment can access this information via the 2-wire serial CMOS EEPROM
protocol. For further information, please refer to SFP Multi-Source Agreement (MSA).
The SFP transceivers are compatible with RoHS.
Regulatory Compliance
The transceivers have been tested according to American and European product safety and electromagnetic compatibility regulations (See Table 1). For further information regarding regulatory certification, please refer to Howfflink regulatory specification and safety guidelines, or contact with Howfflink, Inc.
EEPROM Information:
The serial SFP module contains an EEPROM. It provides access to sophisticated identification information that describes the transceiver’s capabilities, standard interfaces, manufacturer. The serial interface uses the 2-wire serial CMOS EEPROM protocol defined for the ATMEL AT24C01A/02/04 family of components.
Model Number:XSFP-W1490-1G-20km
Brand Name:Howfflink
mode type:single mode/ multi-mode
Laser:DFB/FP
Optical receiver:PIN/APD
Connector:SC/LC
Temperature:Industrial temperature/sta...
Distance:10km/20km/40km/80km/120km
Features
1.25Gbps operation
DFB Laser CWDM Transmitter (1450/1470/1490 nm)
Optical wavelengthrange: λc ± 7.5nm
Optical Transmit DMI function
10km reach on 9/125μm SMF
Wide dynamic PIN-PD receiver
Rx Port Return Loss is no less than 30dB
Standard serial ID information compatible with SFP MSA
SFP MSA package with duplex LC connector
LVTTL logic level RX LOS
Very low EMI and excellent ESD protection
+3.3V single power supply
Operating case temperature: -20 to +85°C
Applications
Switch to Switch interface
Switched backplane applications
Router/Server interfac
CWDM
ATM
SONT/SDH/PDH
FDDI
Fiber Channel
Other optical transmission systems
Standard
Compatible with SFP MSA
Compatible with IEEE 802.3z
Compatible with ANSI specifications for Fibre Channel
Compatible with FCC 47 CFR Part 15, Class B
Compatible with FDA 21 CFR 1040.10 and 1040.11, Class I
Compatible with Telcordia GR-468-CORE
RoHS compliance
Description
The SFP transceiver is high performance, cost effective module supporting data-rate of 1.25Gbps 10km transmission distance with SMF.
The transceiver consists of two sections: The transmitter section incorporates a DFB laser. And the receiver section consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA). All modules satisfy class I laser safety requirements.
The optical output can be disabled by a TTL logic high-level input of Tx Disable. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver.
The standard serial ID information compatible with SFP MSA describes the transceiver’s capabilities, standard interfaces, manufacturer and other information. The host equipment can access this information via the 2-wire serial CMOS EEPROM
protocol. For further information, please refer to SFP Multi-Source Agreement (MSA).
The SFP transceivers are compatible with RoHS.
Regulatory Compliance
The transceivers have been tested according to American and European product safety and electromagnetic compatibility regulations (See Table 1). For further information regarding regulatory certification, please refer to Howfflink regulatory specification and safety guidelines, or contact with Howfflink, Inc.
EEPROM Information:
The serial SFP module contains an EEPROM. It provides access to sophisticated identification information that describes the transceiver’s capabilities, standard interfaces, manufacturer. The serial interface uses the 2-wire serial CMOS EEPROM protocol defined for the ATMEL AT24C01A/02/04 family of components.
