$20.00
Add to Cart
FDM PROTOTYPING SERVICES high quality,low prices, fast turnaround
More than 10 available
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
OVERVIEW
The FDM process works by extruding a thermoplastic material and depositing it layer-by-layer fusing it to the layer beneath it, to form a 3D model. FDM creates functional prototypes using a variety of engineering materials like ABS, and polycarbonate.
When part durability is required, FDM can produce parts using production materials.
PROCESS
Step 1 : The Preparation
FDM begins with a 3D CAD file that is oriented in the appropriate orientation for building the part. The data is then mathematically sliced into 2D cross-sections (layers) along the Z-axis.
Step 2 : The Build
The nozzle is heated to melt the plastic filament and is mounted to a mechanical stage which can be moved in both horizontal and vertical directions.
As the nozzle is moved over the table in the required geometry, it deposits a thin bead of extruded plastic to form each layer and create a two-dimensional cross section of the model. The plastic hardens immediately after being squirted from the nozzle and bonds to the layer below. The platform then descends where the next layer is extruded upon the previous. This continues until the model is completed. The entire system is contained within a chamber which is held at a temperature just below the melting point of the plastic.
Step 3 : The Completion
Once all the layers are drawn and the model is complete, the model is then removed from the platform, and the support structures are removed from the part.
APPLICATIONS
Limited number of prototypes needed (1-10)
Concept Models
Functional testing
For a quote or more information about how we can help your projects, enquiry, 3D files, questions are also welcome, we will do the best job with you.
Please contact with us as bellow:
Name: Yolanda .O
Email: [email protected]
Company: HC-Mold International Co.,Ltd.
Tel: (86) 769 23566161 Fax: (86) 769 85391842
Address: NO.7,MingEn Road, ChangAn, DongGuan City, GuangDong Province, China.
Website: www.moldmake.com . www.hc-mold.cn
Please feel free to contact us for more details
