$1,500.00
On Hold
Rare Contract Plan, Blueprint Wayne County WV, Fort Gay-Nursery Gap, Instruction
Only 1 available
Details
Shipping: USPS calculated - check
Condition: Used
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
#070716468Two rare books are offered here that partner with each other:The large contract plan book contains the actual plans for the construction of a state highway. Each highway worker got a copy of the plans. The second book will assist in reading the plans. However, since I am not privy to all knowledge it takes to read plans, I cannot say whether the book will assist in all areas.Characteristics of the Blueprint/Plan Book is as follows:Fiscal Years 1972-1973 Plans for construction of State Highway Project NO. S-617 (18), Route No 29, Wayne County, Fort Gay-Nursery Gap, Total Project Length 4.218 MilesPages 284, Includes (Estimates of Pay Items, General Notes, Quantity Tables, Mass Diagram, Subgrade Elevations, Superevelation Tables, Reference Points, Plan and Profile, Maintenance of Traffic, Soils Data, Drainage Profiles, Special Details, Bridges, Cross SectionsBoth book are comb bound and although you can't tell from the pictures the plan book is substantially larger.
