Features:
1.Supports both Wireless Access Point and Wireless Repeater modes.
2.Enables wired network wireless ready through the LAN port.
3.Extends the range of your WLAN network easily, covers WLAN signal
in more places.
4.Accesses to the Internet for computers, located on the edge or
outside of the range of your access point.
5.Shares large files, printing and storage quickly and reliably
in wider range in your home or office.
6.Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards.
7.Supports WiFi Protected Setup (WPS) function.
WEP, WPA and WPA2 to ensure network security from unauthorized access.
8.Supports 2.4GHz WLAN network and provides up to 300Mbps transmission rates.
9.Wireless auto-channel selection.
10.User-friendly web-based wizard and easy hardware setup.
11.Plug and play, simple installation and configuration.
12.Built-in antenna, comes with the embedded power supply and power plug.
Mini size, compact shape, beautiful fashion, portable use.

Specification:
Protocol/Standards Wireless IEEE 802.11 n/b/g
Ethernet IEEE 802.3 10/100, IEEE 802.3u, IEEE 802.3ab
Transmission rate Up to 300Mbps
Frequency Range 2.4 ~ 2.4835GHz
Modulation technology 11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
Receiver sensitivity 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Security
Wireless: 64/128-bit WEP, WPA, WPA2


WPS function Yes
Max current 0.12A
Flash 4Mbytes
SD-RAM 32Mbytes
Antenna 2dBi PCBA antennas
Power consumption Less than 4W
Operating temperature 0~40 Celsius degree (32~104 Fahrenheit degree)
Storage temperature -40~70 Celsius degree (-40~158 Fahrenheit degree)
Operating humidity 30% to 90% Relative humidity (Non-condensing)
Storage humidity 3% to 95% Relative humidity (Non-Condensing)


Antenna 2 * Internal PCBA antennas
External connectors 1 * RJ45 for 10/100Base-T LAN
* Factory default reset button
1 * WPS button


LED indicators 1 * Power: Green
1 * Ethernet: Green
1 * Wireless on/off: Green
1 * WPS LED: Green
Casing color White
AC power adapter 100-240V, 50/60Hz, 250mA


Color White
Product size Approx 8 * 6.5 * 5cm / 3.15 * 2.56 * 1.97in
Package:
1 X Wifi repeater with US plug
1 X Ethernet cable with RJ45 connector (1m)
1 X Quick installation guide
