FEATURES

◇　Easy and correct readout.

◇　High measuring accuracy.

◇　Measurements are possible even under a strong magnetic field.

◇　LSI-circuit provides high reliability and durability.

◇　Input overload protection is provided.

◇　LCD display for low power consumption and clear readout even in bright ambient light conditions.

◇　In-line pushbuttons allow one hand operation.

◇　Light-weight and compact construction for easy operation.

◇　Low battery condition is indicated on the LCD display.

SPECIFICATIONS

GENERAL SPECIFICATIONS

Display :LCD (Liquid Crystal Display) Max. display 1999.

Range :9 range, whole range value (from 0.1pF to 20mF)

Overload protection : Display “1”.

Calibrate Adjustment :Have two internal adjustment. One is panel Zero adjustment.

Zero Adjustment :Manual (range:±20pF)

Over-range dispaly :Display“1”.

Sampling Time :0~5second

Operating Temp :0℃ to 40℃.

Operating Humidity :80% MAX.R.H.

Battery :9V (6F22 or the equivalent

Battery Life : alkaline battery: approx.200 hours.

Zinc-Carbon battery approx. 100 hours

Typical consumption current: 3~4mA (RANGE: 200pF-200uF)

Standard Accessories: Test alligator clips (red & black)…1 pair.

Instruction manual………………..1 pc.
