AVR ATMEL PROTOTYPE BOARD ATtiny2313 AT90S2313
More than 10 available, 2 sold
Details
Shipping: US-Mainland: $5.50 (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
AVR-P20 AVR MICROCONTROLLER PROTOTYPE BOARD FOR 20 PIN DEVICES WITH STKxxx COMPATIBLE 10 PIN ICSP CONNECTOR
IDEAL FOR BEGINERS
FEATURES:
* STK200 compatible ICSP 5x2 pin connector for in-circuit programming with AVR ISP, STK200, AVR ISP v3.2 and other
* RS232 Tx, Rx interface with MAX232 IC on socket
* Quartz crystall oscilator circuit
* reset IC circuit
* status LED
* DIL20 microcontroller socket
* +5V power supply based on 78L05
* extension pin headers for each uC pin
* four mounting holes 3.3 mm (0.13")
* FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print
* dimensions 100x80 mm (3.9x3.15")
* bus GND
* bus VCC
Supported devices: AT90S1200, AT90S2313
Number Name Component Q-ty
1 COM port connector DRB-9M 1
2 Power connector standard Jack connector 1
3 AVRISP BH-10 1
4 C1 0,1 mkF 1
5 C2 100mkF x 16V 1
6 C3 10mkF x 25V 1
7 C4, C5, C6, C7, C8 1mkF x 16V (Polarity of capasitors: + pin square pad, - pin round pad) 5
8 C9, C10 22pF 2
9 U1 20-pin DIP socket 1
10 U2 MAX232 1
11 U3 MC340 or other RESET IC 1
12 U4 L7805 1
13 D1 1N4007 1
14 Q1 7,3728 MHz quartz 1
15 R1 8,2k 1
16 R2 470E 1
17 LED any LED 1
18 RTS/DTR 3-pin connector 1
19 J2 2-pin connector 1
