$122.00 Add to Cart

WS-6906 DVB-S FTA Portable Digital Satellite Finder Meter Signal

WS-6906 DVB-S FTA Portable Digital Satellite Finder Meter Signal

More than 10 available

Details

Shipping: US-Mainland: free (more destinations)

Condition: Brand new

*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.


Technical parameters

LNB input
Connections: British F head
Frequency Range: 950MHz-2150MHz
Signal level:-65dBm ~-25dBm
LNB Power: 13/18V, max400mA
LNB switch control: 22KHz
DiSEqC: 1.0 version prefix = o ns = "urn: schemas-microsoft-com: office: office"

Demodulator
Demodulation: QPSK
Symbol rate: 2Mbps ~ 45Mbps
SCPC and MCPC Compatible: Yes

System Processor: 32bit processor (200MHz)
SDRAM: 16Mbyte
FLASH: 4Mbyte

Video: MPEG-2
Rate: up to 15M bits / s
Resolution: 720 * 576,720 * 480
Video Format: PLA / NTSC / SECAM
Audio: MPEG-1 layer 1 & 2
Sound Mode: Mono
Sampling frequency: 32,44.1 and 48KHz

Data: USB port

Battery: Lithium-polymer battery 3000mAh
Voltage: 12.6Volt

Power: 90 ~ 240V AC
Output: 14.4V DC

Size: 9.5x14.5x4.5 (cm)
Weight: 0.5Kg

Packing list:

1. sunshade package and straps * 1
2. audio and video input and output lines * 1
3.USB upgrade line * 1
4. charger * 1
5. Car Charger * 1
