AVR development board for ATmega128A mega128 mega128L
More than 10 available, 1 sold
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
Product Overview
AVR mega128Mini Development Board provides easy way for developing and prototyping with the new mega128high-performance, microcontroller produced by ATMEL. AVR mega128 Mini Development Board has ISP and JTAG port for programming and debugging, 2 UART, 8 status Leds, 4 user Buttons,INT0&INT1, and all of the GPIOs are taken out to make them available for further connections.
Board Features
- CPU: mega128 microcontroller
⑴ISP 5x2 pin connector for in-circuit programming with AVR Programmers .
⑵ jtag 5x2 pin connector for in-circuit programming and Simulating.
⑶ 7805,LM1117 and filtering capacitors.Two kinds of power supply: 6V-12V external power supply and 5.0V USB power supply.
⑷ System power supply selection:5V/3.3V.
⑸ Quartz crystal oscillator circuit 1-16Mhz.
⑹Reset circuit.
⑺ Status LED connected to I/O PC port via removable jumper.
⑻ 1 RS232 DB-9 female connectors.
⑼MAX232 circuit.
⑽ 4 independent keys
⑾ 2 External Interrupts:int0 and int1
⑿PCB, 1.6 mm , blue solder mask, white silkscreen component print .
⒀Dimensions: 77mmx100mm
Packing List:
This product should include the following components:
AVR mega128 Mini Development Board, 1 pcs;
USB power supply cable, 1 pcs;
（CD/DVD is not included in the Package,but we will sent the data to you via e-mail.）
TE57
