Specifications:

* Microphone separate of Camera for Optimum Audio Capture
* Mounting Bracket built on to Receiver for Permanent setups
* Wireless or Wired Configurations
* Wireless Button Spy Camera With Microphone
* Image Device: 1/4 Inch Sony CCD
* Sensor Type: HQ CCD Sensor
* Synchronization System: Internal
* Backlight Compensation: Auto
* White Balance: Auto
* TV System: PAL 628 x 582
* Horizontal Definition: 480 TV Lines
* Angular Field of View: 90 Degrees
* Transmission Frequency: 1.2 GHz spectrum
* Built In Microphone: Max Audio Range = 5 Meters
* Camera: 28 x 23 x 10mm / 1.1 x 0.9 x 0.4in (L x W x D)
* Camera Transmission Unit: 90 x 57 x 21mm /3.5 x 2.2 x 0.8in (L x W x D)
* Receiving Unit: 115mm x 60mm x 21mm
* Transmission Range: Outdoors up to 80 meters, Indoors up to 35 meters (through walls), Adjustable Angle Antennas for Fine Tuning Range



*

How to Set Up a Spy Camera Security System?
o Decide what you want to see on your security system. Front doors, back doors and driveways are popular choices. Other choices may include living rooms, hallways and garages.
o Wireless cameras are not completely wireless. They still need a wire for power. Most systems come with plug in adapter to power each camera. Most power wires are 4 to 6 feet long. The location of your cameras should be close to power outlets. Professional installers may run electrical wire inside walls and conceal the power outlets and adapters in junction boxes.
o Each camera will need to be set to its own channel. Common channels for such systems are labeled A through D or 1 through 4. Drill holes into walls and mount the cameras with screws.
o The wireless camera receiver will be positioned next to the television. Connect the receiver to the television using a cable that has a yellow, red and white connector on each end. Some systems may have an "S-video" connector and cable to connect it to the television. The receiver will also be powered by a plug in wall adapter. Connect it to the receiver and plug it into the wall.
o Set the receiver to channel A or 1 and turn on the television. The channel of the television may need to be set to Game, Video In or some other name designating the input jacks used. Consult your television for more information.
o The view from the camera that is set to channel A or 1 should be visible on the TV screen. Tilt the camera if needed to get the view you desire. Set the receiver to channel B or 2 and repeat with the camera that is set to B or 2. Repeat with the remaining 2 cameras.
o More advanced users may connect the receiver to a VCR, DVR or computer. Digital video capture devices can be used to connect the receiver to the computer. Using video capture software, the video from the cameras can be broadcast on the internet using software such as Yawcam or WebcamXP. HomeCamera.com can also be used to monitor your cameras on the internet.

Package Included:
o 1 x Camera
o 1 x Wired Mode Cable
o 1 x Transmitter
o 1 x Receiver
o 2 x Power Adapters (1 for Transmitter, 1 for Receiver)
o 1 x AV Cable
o 4 x Extra Shirt Buttons (to match Camera)
o 2 x Antennas (for wireless operation)
o 1 x Belt Clip Attachment for Transmitter
o 1 x Durable Case
