200Watt Monocrystalline Solar Panel

200Watt Monocrystalline Solar Panel

10 available

Details

Shipping: US-Mainland: free (more destinations)

Condition: Brand new

*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.

200Watt Monocrystalline Solar Panels Spec.

Model Type WGESO-M-200
Peak Power (Pmax) 200W
Model Weight 17.8Kg (39.3Ibs)
Dimensions 1482x992x50mm (58.3×39.1×1.97inch)
Maximum power voltage (Vmp) 27.21V
Maximum power current (Imp) 7.36A
Open circuit voltage (Voc) 32.72V
Short circuit current (Isc) 7.86A
Maximum system voltage DC 1000V
Temp. Coeff. of Isc (TK Isc) 0.065 %/ C
Temp. Coeff. of Voc (TK Voc) -0.346 %/ C
Temp. Coeff. of Pmax (TK Pmax) -0.488 %/ C
Normal Operating Cell Temperature 45.3±2 C


Data Sheet / Others infor. / Shipping Cost / Payment Method~
About the data sheet / Spec. and more information ,please feel free to contact us Send Mail


You can search in our company website as below ~
http://www.wgeso.com
