$656.12 Add to Cart

205Watt Monocrystalline Solar Panel

205Watt Monocrystalline Solar Panel

10 available

Details

Shipping: US-Mainland: free (more destinations)

Condition: Brand new

*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.

205Watt Monocrystalline Solar Panels Spec.

Model Type WGESO-M-205
Peak Power (Pmax) 205W
Model Weight 17.8Kg (39.3Ibs)
Dimensions 1482x992x50mm (58.3×39.1×1.97inch)
Maximum power voltage (Vmp) 27.301V
Maximum power current (Imp) 7.50A
Open circuit voltage (Voc) 32.80V
Short circuit current (Isc) 8.10A
Maximum system voltage DC 1000V
Temp. Coeff. of Isc (TK Isc) 0.065 %/ C
Temp. Coeff. of Voc (TK Voc) -0.346 %/ C
Temp. Coeff. of Pmax (TK Pmax) -0.488 %/ C
Normal Operating Cell Temperature 45.3±2 C


Data Sheet / Others infor. / Shipping Cost / Payment Method~
About the data sheet / Spec. and more information ,please feel free to contact us Send Mail
