$800.00 Add to Cart

240Watt Monocrystalline Solar Panel

240Watt Monocrystalline Solar Panel

10 available

Details

Shipping: US-Mainland: free (more destinations)

Condition: Brand new

*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.

240Watt Monocrystalline Solar Panels Spec.

Model Type WGESO-M-240
Peak Power (Pmax) 240W
Model Weight 19.3Kg (42.61Ibs)
Dimensions 1640x992x50mm (64.57×39.1×1.97inch)
Maximum power voltage (Vmp) 29.40V
Maximum power current (Imp) 8.16A
Open circuit voltage (Voc) 36.50V
Short circuit current (Isc) 8.50A
Maximum system voltage DC 1000V
Temp. Coeff. of Isc (TK Isc) 0.065 %/ C
Temp. Coeff. of Voc (TK Voc) -0.346 %/ C
Temp. Coeff. of Pmax (TK Pmax) -0.488 %/ C
Normal Operating Cell Temperature 45.3±2 C


Data Sheet / Others infor. / Shipping Cost / Payment Method~
About the data sheet / Spec. and more information ,please feel free to contact us Send Mail
