$42.00
Add to Cart
10Watt Monocrystalline Solar Panel
10 available
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
10Watt Monocrystalline Solar Panels Spec.
Model Type WGESO-M-10
Peak Power (Pmax) 10W
Model Weight 1.7Kg (3.7Ibs)
Dimensions 383x299x34mm (15.1×11.8×1.3inch)
Maximum power voltage (Vmp) 17.82V
Maximum power current (Imp) 0.57A
Open circuit voltage (Voc) 21.96V
Short circuit current (Isc) 0.63A
Maximum system voltage DC 1000V
Temp. Coeff. of Isc (TK Isc) 0.058 %/ C
Temp. Coeff. of Voc (TK Voc) -0.367 %/ C
Temp. Coeff. of Pmax (TK Pmax) -0.485 %/ C
Normal Operating Cell Temperature 44.4±2 C
Data Sheet / Others infor. / Shipping Cost / Payment Method~
About the data sheet / Spec. and more information ,please feel free to contact us Send Mail
You can search in our company website as below ~
http://www.wgeso.com
Model Type WGESO-M-10
Peak Power (Pmax) 10W
Model Weight 1.7Kg (3.7Ibs)
Dimensions 383x299x34mm (15.1×11.8×1.3inch)
Maximum power voltage (Vmp) 17.82V
Maximum power current (Imp) 0.57A
Open circuit voltage (Voc) 21.96V
Short circuit current (Isc) 0.63A
Maximum system voltage DC 1000V
Temp. Coeff. of Isc (TK Isc) 0.058 %/ C
Temp. Coeff. of Voc (TK Voc) -0.367 %/ C
Temp. Coeff. of Pmax (TK Pmax) -0.485 %/ C
Normal Operating Cell Temperature 44.4±2 C
Data Sheet / Others infor. / Shipping Cost / Payment Method~
About the data sheet / Spec. and more information ,please feel free to contact us Send Mail
You can search in our company website as below ~
http://www.wgeso.com











CN, Shanghai
