It can be used as stabilized voltage supply or stabilized current supply
Output voltage can be adjusted from 0 voltage to nominal value continually
It possesses the best degree of stability and corrugation coefficient and perfect protect circuit for overload.
Maximum output current 3A voltage 30V.
Voltage of power:110V±10%(50Hz-60Hz)
Relative humidity: ＜80%
Working status for stabilized voltage:
a. Output voltage will be adjusted from 0 to nominal value continually.
b. The stabilized degree of voltage.
The stabilized degree of power:≤0.1%+2Mv
The stabilized degree of load:≤0.1%+2Mv (The maximum current is less than the nominal value).
The stabilized degree of load: ≤0.1%+5Mv（The maximum current is larger than the nominal value）.
d. corrugation noise: ≤0.5Vrms (5Hz～1MHz, the maximum current less or epual nominal value ).
≤1.0Vrms(5Hz～1MHz,the maximum current larger than nominal value).
e. temperatuer coefficient: ≤300ppM/℃.
Working status for stabilized current:
a. Output current will be adjusted from 0 to nominal value continually.
b. The stabilized degree of voltage≤0.2%+2 mA.
The stabilized degree of load≤0.2%+2mA.
c. Corrugation noise : ≤2 mA Arms.
