ARM7 KIT LPC214X features:
1. the hardware is rich in resources, all resources can be used for LPC214X experiments.
2. rich routine examples, so you get started quickly and shorten the time to learn ARM to accelerate the progress of project development.
3. good technical support forum www.mcu123.net/bbs in ARM LPC2000 series.
ARM7 Kit (LPC214X) standard of using PHILIPS LPC2142 chip, is a cost-effective entry-learning ARM7 board. Dual serial port, USB2.0 port, which can be accessed MMC card (for U disk), for USB sound card (sound good) , LCD12232/1602 LCD interface, EEPROM memory AT24C16.LPC2142 chip parameters: maximum operating frequency of up to 60M (compatible LPC214X chip) which LPC2142 has 16K RAM 64K FLASH 2 × UART 2 × I2C 1 × SPI 1 × SSP SB2.0 8-channel 10-bit A / D 1-channel 10-bit A / D.
ISP can download (one-button auto-complete), this is a big plate of this study the characteristics of this experiment board provides a wealth of LPC214X/LPC213X routines, no one left. You get started quickly and shorten the learning time to accelerate project development progress,
Save you more valuable time.
This board is compatible LPC213X/LPC214X chips
1. AD (thermistor temperature measurement, adjustable potentiometer), DA (USB sound card) conversion.
2. liquid crystal display (LCD12232, LCD1602A).
3. USB2.0 interface, which can be accessed MMC card (U disk), can be used as USB Audio Device (USB sound card).
4. SD (SPI) interface.
5. dual RS232 interface.
6. four keys, eight LED lights, one buzzer.
7. serial ISP (bootloader) download, JTGA debug interface.
8. JTAG interface (facilitate debugging with the emulator, can be equipped with our Mini ARM JTAG Adapter)
9. other functions (speaker output driver - can be directly connected speakers).
* RTC real time clock experiment (chip itself)
* GPIO control experiments, LED (light emitting diode), KEY (keyboards), playing music, experimental buzzer
* Temperature measurement (AD experiment), can measure 0 to 100 degrees
* External interrupt test, the plate mouth to interrupt experiments using P014
* Dual serial port can communicate with a PC or other peripherals can also communicate with each other to do experiments
* Serial EEPROM experiments (IIC communication experiment, simulation IIC) on-board 24C16
* Internal timer experiment (with 51 similar)
* 8 LED bar ... do the volume you can do download progress bar ..
* 122 * 32 graphic LCD display, you can choose the character LCD ....( 1602 dual-channel, multi-choice) / TFT 320X240 ucgui other experiments.
* DAC conversion test (own), this experiment is not generally in the 51's, the USB Audio (USB sound card) experiments can DIY their own standard source generator
* USBHID experiment, USB to serial experiments, this board can do with a USB to serial two serial ports of two experiments.
* Can be an external MMC / SD card, free DIY Reader, U-Mass.
* PWM experiments, SSP experiments, WDT experiment.
* There are people concerned about the ARM IAP experiment ... DIY their own remote BOOTLOADER.
* MP3 player (SD card, you can play MP3, the sound from the speaker output, limited to the LPC2148 chip configuration)
1. ARM7 KIT LPC2148 development board x1
2. serial cable x1
3. USB cable x1
4. speaker x1
5. CD-ROM (LPC2142 development environment and all the routines, related manuals) x1
* ULINK2 (USB interface, JTAG debugger support KEIL, so you better get started quickly)
* J-LINK ARM ICE (compatible SEGGER's JLINK), support ADS, IAR, KEIL, RV
* WIGGLER debugger
* LCD12232 graphic LCD
* LCD1602A character LCD
* TFTLCD 240X320 color LCD .. (based on UCGUI drivers, etc.)
