The GPSMAP 76CSx is a refreshing upgrade of the GPSMAP 76CS, one of our most popular models for outdoor and marine use. This unit features a removable microSD card for detailed mapping memory and a waterproof, rugged housing. The microSD card slot is located inside the waterproof battery compartment. Users can load map data and transfer routes and waypoints through the units fast USB connection.
In addition, this unit features a new, highly sensitive GPS receiver that acquires satellites faster and lets users track their location in challenging conditions, such as heavy foliage or deep canyons. The GPSMAP 76CSx also incorporates a barometric altimeter for extremely accurate elevation data and an electronic compass that displays an accurate heading while standing still.
Considered the mainstay among serious outdoor enthusiasts, the GPSMAP 76CSx and GPSMAP 76Cx offer a large color TFT display and turn-by-turn routing capability. These units also float when dropped in the water. Each unit comes with a blank 128 MB microSD card. Owners of these new x-series handhelds can also purchase new microSD cards that are pre-loaded with MapSource Topo and inland lake maps, BlueChart marine cartography, and City Navigator street maps.
New high-sensitivity WAAS-capable GPS receiver by SiRF
Built-in quad-helix receiving antenna with remote antenna capability
microSD card slot allows for storage of optional MapSource detail (128 MB microSD included)
LED backlit display and keypad
Includes a built-in Americas autoroute basemap with automatic routing capabilities, including highways, exits, and tide data (USA only)
Internal memory is preloaded with a marine point database
1,000 user waypoints with name and graphic symbol; 50 reversible routes
Position formats include Lat/Lon, UTM, Loran TDs, Maidenhead, MGRS, user grid, and more
Audible alarms for anchor drag, arrival, off-course, proximity waypoint, and clock
Large-numbers option for easy viewing; dual-position display mode
Trip computer provides odometer, stopped time, moving average, overall average, total time, max speed, and more
10,000-point automatic track log; 20 saved tracks (500 points each) let you retrace your path in both directions
Elevation computer provides current elevation, ascent/descent rate, minimum/ maximum elevation, total ascent and descent, average and maximum ascent and descent rate
Navigation instructions can be shared with repeaters, plotters, and autopilots using NMEA protocols through the dedicated serial port.
Built-in celestial tables for sun and moon calculations and the best times to fish and hunt
Unit floats when dropped in the water.
Shipping Weight: 0.7 pounds
Detailed Product Information:
Unit dimensions 2.7" W x 6.2" H x 1.4" D
Display Dimensions 1.5" W x 2.2" H, 2.6"-diagonal
Display Color 256-color
Display Resolution Transflective TFT (160 x 240 pixels)
Weight 7.6 ounces with batteries (not included)
Sensors - Electronic compass displays accurate heading while standing still
- Barometric altimeter with automatic pressure trend recording
Battery life 18 hours (typical use) using two AA alkaline batteries
Water resistant IEC 60529 IPX7 standards
Items GPSMAP 76CSx unit
128 MB microSD
USB interface cable
MapSource Trip & Waypoint Manager CD
Any quantities are available. Email me if the quantity you want is not listed or you would like a larger order.
